Basic Specifications
Steel Grade
H Beam Q235/345
Applications
Office, House, Camp, School, Hotel
Key Category
Container House
Wall Type
Sandwich Panel Wall
Service Life
More Than 20 Years
Standard Size
6056X2438X2896mm
Production
3000 Sets/Month
Key Characteristics
🔄
Flexible Assembly: Easy to assemble and disassemble several times without any damage.
🏗️
Modular Design: Can be lifted, fixed, and combined freely to meet different space requirements.
🛡️
Durable Protection: High-performance heatproof and waterproof capabilities.
💰
Cost-Efficient: Significant savings on transportation (4 units can be loaded in one 20ft standard container).
Technical Parameters
| Standard Prefabricated House Specifications |
| Wind Resistance | Grade 11 (Wind speed ≤ 111.5km/h) |
| Earthquake Resistance | Grade 7 |
| Fire Proofing | B2 Grade |
| Live Load (Roof) | 0.5 kn/m² |
| Live Load (Floor) | 2.0 kn/m² |
| Heat Transmission Coefficient | 0.35 Kcal/m²hc |
Material Specifications
- Material: Light steel structure, steel material Q235
- Surface: Sand blasting, epoxy basic painting (55μm), final vinyl acrylic painting (55μm)
- Fittings: 8 standard container corner mould fittings, PVC rainwater pipe
- Floor Structure: 4mm steel girder with 60x40x1.5mm square tube purlins
- Floor Insulation: 75mm rock wool; 15mm plywood or 20mm cement board
- Ceiling Exterior: 1.2mm stamping steel plate with epoxy painting
- Ceiling Inner: 9mm MDF laminated panel or 10mm glass magnesium fire-proof board
- Wall Panels: 75mm thickness EPS/Rock wool/PU sandwich panels
- External Door: Aluminum frame sandwich panel door with cylinder lock
- Windows: PVC white sliding windows (1130*1000mm) with fly screens
Loading & Transport
Bulk packing in container loading: 1x40HQ can efficiently load up to 5 units of 20ft container houses.
Frequently Asked Questions
1. How long is the expected service life of the container house?
The standard service life is more than 20 years, depending on the environment and maintenance.
2. Can these units withstand high winds and earthquakes?
Yes, they are engineered for Wind Resistance Grade 11 (up to 111.5km/h) and Earthquake Resistance Grade 7.
3. What are the main insulation materials used in the walls?
We typically use 75mm EPS, Rock Wool, or 50mm PU panels for optimal thermal insulation.
4. How many units can be shipped in a standard shipping container?
A single 40FT HQ container can transport approximately 5 to 6 units when packed in bulk.
5. Is the container house fireproof?
The materials used meet the B2 grade fireproof standard, ensuring safety for various uses.
6. What is the production capacity for this model?
We have a production capacity of up to 3000 sets per month to support large-scale projects.
